| Tile Type | Glazed Steel | Certification | CE, ISO, SGS |
| Usage | Roof, Wall | Rolling Thickness | 0.3-0.8mm |
| Forming Speed | 15 M/Min | Voltage | 380V 60Hz |
| Machine Frame | 350mm H Beam Structure, with 18 mm Welded Steel | Roller Material | High Grade 45# Forged Steel Chromed Treatment |
| Main Motor | 5.5+4 Kw | Cutting Type | Hydraulic Post Cutting |
| Feeding Width | 1220mm | Roller Stations | 18 Rows |
Metal Trapezoidal IBR RIB PBR R TR4 TR5 PV4 AG Panel Iron Sheet Roofing Sheet Roll Forming Making Machine
Roofing sheet has many different shapes; usually, different regions have unique popular designs. We customize the machine based on specific demands.
Uncoiling → Feeding Material → Roll Forming → Hydraulic Cutting → Products Receiving
| Machine Parameter Details | |
|---|---|
| Raw Material | PPGI, PPGL |
| Material Thickness | 0.3 - 0.8mm (31-21 Gauge) |
| Shaft Diameter | Φ75mm |
| Forming Speed | About 15m/min |
| Work Power | 9.5 Kw |
| Cutting Blade Material | Cr12Mov, with lifespan exceeding 1 million cuts |
Feeding Device: Features 2 rotatable rollers to reduce friction and stainless touch rollers to prevent material scratches. Includes a hand wheel for accurate width adjustment.
Roll Forming Device: 18 stations with 45# steel rollers (quenched/chromed). The frame utilizes heavy 350H steel with diagonal bracing for maximum stability.
Automatic Shearing System: Dual oil cylinder system for enhanced stability. Cutting length tolerance is within ±2mm. Low noise and safe operation.
PLC Control System: Delta (Taiwan) PLC with touch screen. Supports English and Chinese. Easy adjustment of product length and quantity.
