Product Description

📊 Basic Info.

Model NO.

YXUP-10D

Customized

Certification

RoHS, CE, En12830

IP Rating

IP55

Measuring Medium

Temperature

Shell

ABS

Specification

85*38*12mm

HS Code

9025199090

📝 Product Description

Model	YXUP-10D	YXUP-10	YXUP-11LT	YXUP-170
Probe Type	Built-in probe			Built-in PT1000
LCD	Yes	No
Parameters	Temperature			Dry ice temperature
Measuring Range	-30~70ºC		-40~70ºC	-80~70ºC
Accuracy	±0.5ºC		±0.3ºC (-10~65ºC)	±0.5ºC (-30~70ºC)
Storage	30240 groups			8640 groups
Sampling Interval	10 seconds to 18 hours
Battery Life	About 2 years (25ºC)			About 30 days (-80ºC)
Interface	USB 2.0
Protection	IP55

YXUP series is a disposable PDF temperature, humidity and dry ice temperature recorder, ideal for drugs, vaccines, food, and equipment sensitive to environmental conditions during cold chain transportation and GSP/GMP quality management.

🏢 Company Profile

📜 Certifications

❓ Frequently Asked Questions

How long is the battery life of the YXUP series?

The battery life is approximately 2 years under standard conditions (25ºC, 15-minute interval) for standard models, and about 30 days for dry ice models at -80ºC.

Is the recorder water-resistant?

Yes, the device features an IP55 protection rating, making it suitable for various logistics environments.

How do I start and stop the recording?

Recording is started by pressing the button. It can be stopped by pressing the button, automatically when storage is full, or when inserted into a USB port.

Do I need special software to read the data?

The device generates PDF reports. For advanced analysis, PoChain or PidifiX software (Windows compatible) can be used.

What certifications does the product hold?

The YXUP series complies with CE, ROHS, and EN12830 standards, ensuring high quality and reliability for pharma logistics.
