| Glass Material Type: Laminated Glass / Sandwich Glass / Interlayer Glass |
In order to guarantee the quality of laminated glass, PVB film could be imported from Du Pont of USA or Sekisui of Japan. We also utilize high-quality Chinese brands for PVB interlayers known for their exceptional transparency. This glass can be further processed into tempered laminated glass, glass with holes, or insulating glass units.
🏠 Applications
This product is widely used for bullet-proof and burglar-proof installations, showcases, counters, aquariums, skylights, long corridors, and sidelites, performing exceptionally well in both extreme cold and hot environments.
📏 Specifications
Max. Size: 2440mm * 6000mm | Min. Size: 300mm * 300mm
PVB Film Thickness: 0.38mm - 3.04mm
Typical Glass Thickness (mm): 4+0.38+4, 5+0.38+5, 4+0.76+4, 5+0.76+5, etc.
PVB Colors: Transparent, Milk, Blue, Dark Grey, Light Green, Bronze, etc.
Standards Compliance: EN 12543; ANSI Z 97.1 200; BS 6206
⭐ Competitive Advantages
Extremely High Safety: The PVB interlayer withstands penetration from impact. Even if the glass cracks, splinters adhere to the interlayer rather than scattering.
Energy-Saving: PVB interlayer impedes the transmission of solar heat and reduces cooling loads.
Sound Control: The special laminated construction effectively reduces sound spread, making it an excellent absorber of noise.
Ultraviolet Screening: Filters out at least 99.5% of UV rays, preventing furniture and curtains from fading.
Aesthetic Appeal: Tinted interlayers beautify buildings and harmonize their appearance with surrounding views.
❓ Frequently Asked Questions
What makes laminated glass safer than standard glass?
Laminated glass features a PVB interlayer that holds glass fragments together upon impact. This prevents dangerous shards from scattering and provides resistance against forced entry and bullets.
Can this glass help in reducing energy costs?
Yes. The PVB interlayer helps block solar heat transmission, which reduces the load on air conditioning systems and lowers electricity consumption.
What are the maximum dimensions available for production?
The maximum size we can produce is 2440mm by 6000mm, suitable for large-scale curtain walls and architectural projects.
Does the glass provide protection against fading furniture?
Absolutely. Our laminated glass filters out at least 99.5% of ultraviolet (UV) rays, which are the primary cause of fading in furniture, carpets, and curtains.
Is soundproofing an advantage of this product?
Yes, the laminated structure is an effective sound absorber, making it ideal for buildings in noisy urban areas or near airports.
What certifications does the glass meet?
The product complies with international standards including EN 12543, ANSI Z 97.1 200, and BS 6206.
