| Model | M4040 |
| Material | Fiberglass Reinforced Plastic (FRP) |
| Thickness | 38mm |
| Mesh Size | 40*40mm |
| Weight | 49 Kg/Panel |
| Installation | Bolt Fixing |
| Surface | Concave Surface |
Fiberglass molded grating is a high-performance composite product widely used in industrial, commercial, and public infrastructure. It is manufactured by combining continuous fiberglass rovings with thermosetting resins, forming a one-piece reinforced grid structure.
Key Performance Features:
| Thickness (mm) | Mesh Size (mm) | Bar Thickness (up/under) | Panel Size (mm) | Weight (kg/m²) | Load (kg/m²) |
|---|---|---|---|---|---|
| 25 | 40*40 | 5.5/4.5 | 1220*3660 | 11 | 150 |
| 30 | 40*40 | 6.0/4.5 | 1220*3660 | 14 | 250 |
| 38 | 38*38 | 7.0/5.0 | 1220*3660 | 19.5 | 1200 |
| 50 | 50*50 | 7.0/5.0 | 1220*3660 | 23 | 1800 |
Pallets (Wooden or Steel Frame), Plastic Shrink Film, Edge Protectors, and Heavy-duty Binding Belts to ensure zero damage during global transit.
FRP grating is significantly lighter, corrosion-resistant, non-conductive, and requires almost no maintenance compared to traditional steel grating.
Yes, our FRP gratings are formulated with flame-retardant resins and meet international fire safety standards such as ASTM E84.
Absolutely. We add special UV inhibitors to our resin mix to ensure high durability and resistance to sunlight exposure.
Selection depends on the load requirements and span distance. Common thicknesses include 25mm for walkways and 38mm or 50mm for heavy industrial loads.
Yes, we offer concave surfaces, sanded grit surfaces, or embedded quartz options to provide maximum traction in oily or wet conditions.
Standard colors include yellow, grey, and green, but custom colors can be produced based on specific project requirements.
