Explosion Proof Vibration Analyzer with Temperature Measuring and Touch Screen
Explosion Proof Vibration Analyzer with Temperature Measuring and Touch Screen
Explosion Proof Vibration Analyzer with Temperature Measuring and Touch Screen
Explosion Proof Vibration Analyzer with Temperature Measuring and Touch Screen
Explosion Proof Vibration Analyzer with Temperature Measuring and Touch Screen
1 / 5
Explosion Proof Vibration Analyzer with Temperature Measuring and Touch Screen
Explosion Proof Vibration Analyzer with Temperature Measuring and Touch Screen
Explosion Proof Vibration Analyzer with Temperature Measuring and Touch Screen
Explosion Proof Vibration Analyzer with Temperature Measuring and Touch Screen
Explosion Proof Vibration Analyzer with Temperature Measuring and Touch Screen

Explosion Proof Vibration Analyzer with Temperature Measuring and Touch Screen

Certificate: CE and Ex
Transport Package: Corrugated Carton with Styrofoam Insert
Specification: 465g
Send Inquiry

Product Description

Basic Info.

Model NO. RH712
Trademark RONDS
Origin China
HS Code 9031809090
Production Capacity 500/Month

Product Description

Touch Screen
Route measurements downloaded from PC software
Waveform/spectrum analysis and alarm remind
Manual input function
Infrared temperature measurement
Set equipment status
Multi-communication: Wi-Fi or USB
Camera function
Professional PC analysis software
Explosion proof version available
CE marking available
Explosion Proof Vibration Analyzer
Items Specification
ChannelCH1: Vibration (ICP accelerometer), voltage (±5V AC)
Data acquisitionFreq: 2~10kHz; Sampling: 25.6KHz; A/D: 16 bit; Precision: ±2%
Infrared detectorRange: -30 ~ 420ºC; Precision: ±2% or ±2ºC; Distance coeff: 25:1
Dimension195 × 80 × 37 mm; Grip: 68 × 31 mm
LCD3.5 inch IPS TFT capacitive touch screen, 640×480 pixels
WeightNormal: 465g / EX: 455g
Keyboard21 keys with backlight; Life: 2 million times
EnvironmentTemp: -10~50ºC; IP65 Protection (Dust/Water proof)
Battery/Work TimeCharge: 4h; Continuous work > 10 Hours
StorageStandard 1G; Expandable 8GB Micro SD card
AdditionalRFID recognition; 5MP Auto-focus camera; Flashlight
CertificationExibIIBT4 Gb; CE Certification

Frequently Asked Questions

Is the RH712 suitable for hazardous environments?
Yes, an explosion-proof version (ExibIIBT4 Gb) is available as an option for industrial safety.
How can I transfer data to a PC?
The device supports multi-communication methods, including both Wi-Fi and USB 2.0 connectivity.
Does it support temperature measurement?
Yes, it features an internal infrared temperature detector with a range of -30ºC to 420ºC.
What is the battery life of the device?
The RH712 provides more than 10 hours of continuous working time after a 4-hour charge.
Is the screen easy to operate in industrial sites?
The device is equipped with a 3.5-inch IPS capacitive touch screen and a 21-key backlit keyboard for easy use.
Can I record visual evidence of equipment status?
Yes, it includes a 5-million pixel auto-focus camera and a flashlight for clear documentation even in dark areas.
